IPG Laser Source Pallet Exchange Stable Fiber Laser Cutting Machine
Bolt Series is Penta's high end series for customers that demands extremely high performance and efficiency.
Sheet metal laser cutting has many advantages that has led to great results. High accuracy is one of the most important ones. This allows the laser to cut off unlimited and complex shapes, clean cutting that requires little or no finishing and generating a minimum amount of heat. All this in short processing times and with optimum processing quality. PENTA laser has proven itself in a wide range of industries including automotive manufacturing, aerospace, light-fixture, kitchen ware, stainless steel, decorative maerials, case and cabinet ect. In the broad industrial application of laser technology, PENTA plays a decisive role in most fields.
Features
-IPG RAYCUS Laser Source 1kw to 12kw at your choice
-Auto Focus Cutting Head dedicated for high power (Precitec)
-Dedicated laser CNC that makes the best and most of the laser
-Fast pallet exchanger and full enclosure
-Double servo motor driven synchronously, bring higher speed and acceleration
-Double driving synchonous technology make sure high speed and precision cutting
-Handy embedded cutting database
Technical Specification
| Model | BOLT 4025 |
| Rate output power | 2400 W |
| Rapid Speed | 180 m/min |
| Maximum Acceleration | 2.2 G |
| Accuracy | ±0.03 mm/m |
| Mechanical Repeatability | ±0.01 mm/m |
| Maximum cutting thickness of mild steel | 18 mm |
| Maximum cutting thickness of stainless steel | 8 mm |
| Working Table | 4000 mm ×2500 mm |
Advantages
Efficient Control System
New Z32 real time CNC system, with dynamic and geometric JERK control. The date exchange between CNC system and machine drive system is adopted with fiber and power modulation for the ultimate cutting quality in the corners
Imported Operating System Smart Manager
Smart Manager is originally imported from Europe. This software is based on the Windows
XP system and can fully interface with Italy CNC system which original imported. Therefore the real control of the machine, the laser source and software update is more convenient and fast.
Stable Mainframe
The base consists of foundation, working table, beam,slider, ram, cooling system,pneumatic system,
suction system,dross cleaner, enclosure and so on.
Imported nesting software function
Based on AUTO CAD/CAM automatic program nesting software and easy to use, Multilayer nesting function to intensively increase the sheet usage rate
Pre-perforation System
Accomplish the pre-perforation as settled
Samples
