15000W Super High Power Fiber Laser Cutting Machine Cutting 50mm Stainless Steel
BULL PLUS 16035 CNC Laser Cutting Machine is suitable for processing large format materials such as mild steel, stainless steel, aluminum alloy, titanium alloy, high temperature alloy ect., the BULL Series has the advantages of power saving, fast moving, fast cutting, fast piercing and so on, the production efficiency is promoted more than 50% which perfect substitute for water jet or plasma or flame cutting machine.
It's GANTRY structure and adopts fixed working table,the base consists of foundation, working table, beam,slider, ram, cooling system,pneumatic system,suction system,dross cleaner and so on.
Company Introduction
PENTA LASER is a joint-venture by El.En Group and Chutian Laser Group, both accumulating in laser industry for over 30 years. PENTA LASER is devoted in making high power laser cutting system, brings in advanced technology from Italy and more than 90% of the parts are originally imported from famous brands company, the final integration is done is china under the quality testing by Italian engineers. We creat laser application revolution in the smart manufacturing era, and creat value for customers. We Developed the first 8000W, the first 10000W, the first 12000W, and the first 15000W fiber laser cutting machine in China, and we keeping developing the potential of our machines.
We have Top-Speed Metal Laser Cutting Machine BOLT Series; Pipe Laser Cutting Machine WHIRL Series; 3D Laser Cutting Machine GAN3020; Laser Welding Machine according to customer's requirement and Large Format Laser Cutting Machine BULL Series
With the rapid development of PENTA LASER, we now have two manufacture bases located in Wenzhou(50,000㎡) and Wuhan(13,000㎡), and in 2019, we will start the construction of Shandong factory in Linyi,forming a situation of tripartite confrontation of East, Middle and North of China.
CNC Control System
Smart Manager is originally imported from Europe. This software is based on the Windows XP system and can fully interface with Italy CNC system which original imported also. Therefore the real control of the machine, the laser source and software update is more convenient and fast.
Friendly interface, easy to learn and operation; easy to edit the numerical control program and high readability.
Cutting parameters database is available, at the same time the real time adjustment to the cutting quality.
Optimize various fast moving mode, have the function of “frog jump” and turn off the assisting gas automatically when fast moving.
Multilayer nesting function to intensively increase the sheet usage rate
Technical Specifications
| Series | BULL PLUS |
| Model | BULL8020/8035/10035/12035/16035/18035/20035... |
| Laser Power | 15000W |
| Table Travel | Customizable(4m-30m) |
| Accuracy(VDI 3441) | ±0.1mm/m |
| Repeatability | ±0.08mm |
| Rapid Speed | 80m/min |
| Maximum Acceleration | 0.8G |
| Z Travel | 200mm |
| Cutting Ability | MS:35mm SS:50mm |
Exhibitions
Aftersales Service
PENTA LASER estabilished service and training centers in 35 major cities and more than 10 countries all over the world. Provides installation and training service according to customer's demand.Training will be devided into two parts,a week in PENTA LASER and a week in demander's factory. Training is mainly about maintenance, operation, laser protecting, cutting parameters, graphics edition, common debugging and so on.
